NA2XSY 12/20 KV
AL/XLPE/CTS/PVC
(Copper Conductor, XLPE Insulated, Copper Tape Screen, PVC Sheathed)
Standard Specification : SNI IEC 60502-2 : 2009

Application:
For power stations and switchgear as well as stations because of small bending radius in confined spaces indoors. As underground because of light weight where installation conditions are difficult.

Special Features on Request :

• Oil Resistance
• UV Resistance
• Flame Retardant Cat A, B, C
• Flame Retardant Non Category
• Heat Resistance
• Anti Termite
• Anti Rodent
• Low Smoke Zero Halogen
• Nylon Coated

Note:
Conductor Shape
35 - 630 sqmm supplied in compacted circular stranded (cm) conductor shape

Electrical Data

Nom. Cross Section Area Overall Diameter Cable WeightConductorInductanceCurrent-Carrying Capacity at 30^oCShort circuit current at 1 secDC Resistance at 20^oCAC Resistance at 90^oC
